Backtracking Horizontal Single Axis 2P Solar Tracking Controller
Solar tracking control system adjust the direction that a solar panel is facing according to the position of the Sun in the sky. Performances and productivity of solar plant are heavily depend on how accurately receiving units are pointed to the sun, hence the tracking control intelligence is crucial to drive maximized energy and profit yield. As certified by independent third parties, TCI exceeds state-of-the-art systems delivering seamless, high-precision control intelligence.Our tracking control unit is used to control the tracker movements by means of the integrated inclinometer and the powerful motor control output.
Technical Parameters of Backtracking Horizontal Single Axis 2P Solar Tracking Controller
| Technical parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 28VDC motor |
| Terrain Adaption | Up to 20% N-S slope |
| Structure Material | Hot dip galvanized steel |
| Power Consumption | 0.2-0.5kWh/day |
| Power Supply Mode | Powered by PV strings, back-up lithium battery |
| Standard Design Wind Speed | 18m/s |
| Module Supported | All commercially available modules |
| Operation Temperature | -40℃ - 70℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Tracking Accuracy | ≤ 1° |
| String-Powered | Yes |
| Backtracking | Yes |
| Communication Options | LoRa wireless /RS 485 cable |
| Night Position | Yes |
Advantage:
1. Efficient and fast engineering of the entire automation reduces time and costs by up to 20 %
2. Fully programmed and tested function blocks of the free solar tracking toolbox
3. Fast, precise, and reliable adjustment of the tracking axes
4. Simplified commissioning and remote diagnostics by means of the integrated web server
5. Easy communication among all the components of a solar farm
6. Increased energy yield through backtracking function
Functions:
1. Smart control algorithm. Adopt time control + angle sensor to form closed-loop control, no Angle accumulation error, high-precision and reliable tracking;
2. Comprehensive protection mechanism. Wind protection, snow protection, limit protection, over-current protection, over/under- voltage protection, etc;
3. Fault self-diagnosis mechanism. System automatic detection, automatic judgment, automatic alarm, automatic recovery after troubleshooting, etc;
4. Modular design, easier for on-site troubleshooting and maintenance;
5. Working temperature: -40℃ ~ 70℃;
6. Protection grade IP68, suitable for all kinds of outdoor environments;
About us:
Good Future Solar is a high-tech company in the clean energy industry, registered in China, address: Zhengzhou East New District, Henan Province, China. Our company is committed to provide the solar products of high reliability with competitive price to our domestic and foreign customers. Strive to build our brand in terms of leading technology, high quality and efficient service.Good future solar has a professional management team, we have gains rich experiences on the solar power generation, and the designing, manufacturing, commissioning of the single axis tracking system. Our company always values customer’s needs as the highest priority, ready to provides technical support to our customers at any time, to solve their problems in the operation of PV power plant and solar tracking system.
Product Tags:
|
|
Backtracking 0.5kWh Single Axis Solar Tracker Controller 1000V Images
|
